Lenovo ThinkServer RS160 Rack Server
Powerful, affordable, easy-to-manage entry rack server
- A choice of processor for performance and price
- Plenty of DDR4 memory for performance
- Flexible storage options
- Integrated systems management hardware
- XClarity software for easy management
- Energy-efficient power supply
- A choice of server OSes
Lenovo ThinkServer RS160 Rack Server is an excellent entry-server for growing businesses. Featuring powerful Intel processors and enterprise-class storage and networking, it offers up to 12Gbps data transfer rate as well as 2x the memory and 33 percent more internal storage capacity than its predecessor. The Lenovo ThinkServer RS160 Rack Server is ideal for web hosting, mail serving, file-and-print serving, video streaming, as well as a wide range of general-purpose productivity applications.
Lenovo ThinkServer RS160 Rack Server
-
Features
Highlights
- Choose from models containing one Intel® Xeon® E3-1200 v6 series, Core i3, Pentium, or Celeron processor
- Up to 64GB of fast 2400MHz DDR4 ECC memory in four DIMMs
- A choice of 3.5-inch SAS/SATA HDDs, 2.5-inch SAS/SATA HDDs, 2.5-inch SSDs, and M.2 SSD
- Up to 20TB of storage (3.5-inch SATA)
- Software RAID-0/1/10/5 standard; optional hardware RAID-0/1/10/5/6
- 80 Plus Gold power supply
- Integrated BMC for systems management
- XClarity Administrator support (limited)
- A choice of four rack-mounting methods
Increased performance
The Lenovo ThinkServer RS160 Rack Server is an excellent entry-server for growing businesses. Featuring powerful Intel® processors and enterprise-class storage and networking, it offers up to 12Gbps data transfer rate as well as 2x the memory and 60 percent more internal storage capacity than its predecessor. Th Lenovo ThinkServer RS160 Rack Server is ideal for web hosting, mail serving, file-and-print serving, video streaming, as well as a wide range of general-purpose productivity applications.
Built-in value and flexibility
The Lenovo ThinkServer RS160 Rack Server features a full line of powerful Intel processors, from Celeron to Xeon®, and up to 64GB of DDR4 memory. It provides business flexibility with multiple storage types and form factors, including up to 20TB of internal storage and 128GB of M.2 drive support for additional scalability. Multiple server OSes are available and the rack is available with 2-post and 4-post rail rack-mounting options.
Customer-friendly
Lenovo servers continue to be rated the most reliable x86 servers on the market and have the highest customer satisfaction.*,† The RS160 is no exception. Its shallow chassis depth promotes greater in-rack airflow and it has an 80 Plus Gold-certified power supply. Easy-to-use Lenovo XClarity system management tools provide business-class reliability and management to reduce costs and downtime. These are the same tools used on Lenovo’s high-end, two-socket rack systems.
*2016-2017 Global Hardware, Server OS Reliability Report, ITIC; October 2016.
†2H16 Corporate IT Buying Behavior and Customer Satisfaction Study, TBR; December 2016.
Tech Specs
Form Factor/Height 1U (411mm/16.2 in. deep)Processor (Max) Intel® Pentium, Core i3, Xeon® E3-1200 v6; CeleronCache Up to 8 MBNumber of Processors 1 (up to 4 cores)Memory (Max) Up to 64GB (4x 16GB) 2133/2400 MHz DDR4 ECC UDIMMsExpansion Slots 1 PCIe 3.0 x16Storage Bays 1x M.2, plus either 2x 3.5-inch or 4x 2.5-inch non-hot-swap, plus optional optical driveMaximum Internal Storage 20TB (7,200rpm) 3.5-inch SAS/SATA; 8TB (7,200rpm) SATA 2.5-inch; 4.8TB 2.5-inch SAS (10,000rpm); 3.84TB 2.5-inch SSD; 128GB M.2 SSDRAID Support Software RAID-0/1/10/5 (standard); optional hardware RAID-0/1/10 (plus RAID-5/6 with upgrade key)Network Interface 2x 1GbE (standard), plus 1x 1GbE dedicated management portPower Supply (Std/Max) 300W 80 Plus Gold (90% efficient) non-hot-swapOptional Rack Mounting 2-post rail, 4-post railSecurity Optional TPM/TCMSystems Management Onboard BMC; XClarity support§; Power Planner tool; easy update and startupOperating Systems Supported Windows Server 2012/2012 R2/2016, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere ESXiLimited Warranty 1 or 3-year (model-specific) parts and laborSpecifications may vary depending upon region.
