ThinkSystem SR630 Rack Server
Built for business, with business-critical versatility
ThinkSystem SR630 Rack Server
Tech Specs
| DESCRIPTION | SPECIFICATIONS |
|---|---|
| Form Factor/Height |
1U rack server
|
| Processor (max)/Cache (max) |
Up to 2 second-generation Intel® Xeon® Platinum processor, up to 205W
|
| Memory | Up to 7.5TB in 24x slots, using 128GB DIMMs; 2666MHz / 2933MHz TruDDR4 |
| Expansion Slots |
Up to 4x PCIe 3.0 slots (with two CPUs), including 1x dedicated PCIe for RAID adapter
|
| Drive Bays | Up to 12 bays (includes 4x AnyBay): 3.5″: 4x hot-swap SAS/SATA; 2.5″: 4x hot-swap AnyBay + 6x hotswap SAS/SATA + 2x rear; or 8x hot-swap SAS/SATA; or 10x hot-swap U.2; plus up to 2x mirrored M.2 boot |
| HBA/RAID Support | HW RAID (up to 16 ports) with flash cache; up to 16-port HBAs |
| Security and Availability | TPM 1.2/2.0; PFA; hot-swap/redundant drives, fans, and PSUs; 45°C continuous operation; light path diagnostic LEDs; front-access diagnostics via dedicated USB port |
| Network Interface | 2/4-port 1GbE LOM; 2/4-port 10GbE LOM with Base-T or SFP+; 1x dedicated 1GbE management port |
| Power | 2x hot-swap/redundant: 550W/750W/1100W AC 80 PLUS Platinum; or 750W 80 AC PLUS Titanium |
| Systems Management | XClarity Controller embedded management, XClarity Administrator centralized infrastructure delivery, XClarity Integrator plugins, and XClarity Energy Manager centralized server power management |
| Operating Systems Supported |
Microsoft, SUSE, Red Hat, VMware vSphere. Visit lenovopress.com/osig for more information.
|
| Limited Warranty | 1- and 3-year customer replaceable unit and onsite service, next business day 9×5, optional service upgrades |
Specifications may vary depending upon region.
-
3D Tour
-
Features and Benefits
Future defined data center
Lenovo delivers cost-effective, reliable and scalable solutions by combining industry-leading technology and the world’s best software-defined offerings with Lenovo ThinkShield, XClarity, and TruScale Infrastructure Services to manage the life cycle of your data center needs. ThinkSystem SR630 provides support for data analytics, hybrid cloud, hyperconverged infrastructure, video surveillance, High Performance Computing and much more.
Workload-optimized support
Intel® Optane™ DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offers an unprecedented combination of high capacity, affordability and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware.*
* Based on Intel internal testing, August 2018.
Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.
Empowering IT management
Lenovo XClarity Controller is the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks. Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95% versus manual operation. Running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.
